137311900â Frigidaire Washer Pump is a replacement drainâ pump âŁassembly used in â¤many Frigidaire residential washing machines; it is⢠indeed a compact, electrically driven pump that evacuatesâ wash and rinse water from âthe tub and directs it âinto⤠theâ household drain.⢠The component typically âŁconsists âŁof a âŁsmall electric motor, an impeller enclosed in âa plastic housingand integral mounting and electrical connectors that âŁallow it too be fitted to the washer’s drain â¤port.
Inside the appliance, theâ pump’s primary role isâ to remove water from the tub âŁat the end of âfill â¤and spin cycles and⣠to â¤clear water from the detergent and pump housings between cycles. It interfaces mechanically âwith the âtub and âŁdrain hose⢠and interfaces electrically with the washer control board and cycle âtimer; it â˘is also functionally linked to level-sensing componentsâ (pressure switch or âwater level sensor)â and âdoor/lid safety interlocks that â˘determine when drain operations⢠are permitted. Proper âsealing, unobstructed â¤impeller operationand reliable electrical connection are essential for the pump to maintain expected flow rates and toâ avoid leaks, noiseor motorâ failure.
This article will⤠describe âtheâ pump’s function and typical construction,⣠outline compatibility and âfitment considerations for technicians and âowners, summarize commonâ failure symptoms (such as: no drain,⢠persistent⤠humming, excessive vibrationorâ leaks), âand provide âŁa structured approach to troubleshootingâ and diagnosis. â¤It will also cover practical replacement considerations⣠such⢠as mounting orientation, hose and clamp inspection, electrical checks to isolate âmotor âfaultsand safety precautions⤠to follow during service.
Table of Contents
- Function and Role of â¤the Frigidaire Washer Drain Pump in⤠Water Removal and Flow Control
- How the 137311900 Frigidaire washer Pump⢠Operates Inside the â¤Appliance: Mechanical,⢠Electricaland Hydraulic Interaction
- Common â¤Failure Symptoms and Diagnostic Tests⤠for âPump motor, â˘Impellerand Seals
- Replacement Considerations andâ Step-by-Step Installationâ for the â˘137311900 Pump assembly
- Q&A
- Theâ Way Forward
Function and Role â¤ofâ theâ Frigidaire Washer Drain Pump in Water Removal and Flow Control
The primary⤠function of the 137311900 Frigidaire Washer Pump is to evacuate wash and rinse water⤠from the tub âand force it thru the drain hose to the household plumbing. âThis component is a sealedâ motor-and-impeller â˘assemblyâ designed to run on the appliance’s AC âsupply and to⤠deliver⣠a relatively high volumetric flow atâ low head for short intervals during the wash cycle. âIn operation the pump âis âenergisedâ by the washer’s electronic control or⢠timer only⤠during drain or âintermittentâ purge âoperations; hydraulic design choices such as impeller âŁsize, volute geometryand any integrated check valve determine how quickly the tub âŁemptiesâ and how âthe pump responds to partial restrictions or âŁvertical liftâ in the drain run. Technician observations such as a humming motor with no⢠fluid movement, slow drain, âŁor foreign-object debris caught in the⤠inlet are consistent with worn â˘or obstructed pumpâ components rather than control-system faults in many cases.
The pump also plays a central⤠role in flow controlâ within the machine’s waterâ management system by working in concert with the water-level⢠sensor andâ the control electronics: the â¤controller energises the⤠pump until sensors report that the âŁtarget drainâ level is reached,so pump hydraulic⣠performance (flow vs. head) directly⤠affects â˘cycle timing âŁand spin â¤behavior. âPractical compatibility checks forâ replacement include verifying the electrical connector pinout, âmounting flange and seal dimensionsand rotational direction of the â˘impeller;⣠measuring theâ motor âwinding â˘resistance with a multimeter⢠and confirming free impeller ârotation are fast functionalâ tests before â˘installation.Typical service symptoms, diagnostic checks,â and a short âtechnical reference are provided below âtoâ aid repair decisions.
- Common⤠symptoms:â no drain but motor hums, â˘intermittent draining, audible grinding âor rattling, leaks at pump housingor high current draw.
- Basic checks: inspect⢠inlet screen forâ debris, âverify connector voltage âŁduring drain command, measure winding resistance, â˘and confirm âŁcorrect mechanical fitment.
| Item | Description |
|---|---|
| Replacement Part | 137311900 Frigidaire Washer Pump |
| Typical Supply | 120 â˘VAC â¤(residential,model-dependent) |
| typical Current Range | Approximatelyâ 0.5-2 A under normal load (model and load dependent) |
| Typical Flow | Order of 10-30 L/min at low head; actual performance varies with vertical â˘liftâ and hose⣠configuration |
| Service â˘Checks | Visual debris inspection, impeller spin test, connector pinout verification, winding resistance measurement |
How âthe 137311900 Frigidaire Washer Pump⣠Operates Inside the Appliance: Mechanical, Electricaland⣠Hydraulic Interaction
The 137311900 Frigidaire Washer Pump is a compact centrifugal⢠drain pump assembly âŁthat âcouples a small electric motor to a â˘molded impeller and housing. Mechanically it mounts â˘to the washerâ tub and⣠connectsâ to the drain hose; the impeller convertsâ motor torque intoâ fluid flow and⣠pressure required to evacuate the âwash tub during âdrain âand spin phases. Electrically the⢠pump receives switched supply â¤from the âwasher control board (often through a harness⤠and connector)⢠and will âŁrun onlyâ when the controller energizes the âappropriate circuit, so correct connector⣠orientation âand matching âcoil voltage are required for⣠compatibility.In practise, techniciansâ verify fit by matching⢠mounting tabs, hose diameter, âŁand âŁconnector pinout ratherâ than relyingâ solely on model numbers, asâ several Frigidaire model series use similar pumpâ assemblies with slight variations in outlet orientation or harness length.
Inside the appliance theâ pump’s mechanical, electricaland hydraulic subsystems interact continuously: the motorâ provides rotational â¤energy, theâ impeller imposes a centrifugal⣠pressure head that overcomes static water âŁlevel and discharge backpressureand the housing and hoses defineâ flow restrictions and⢠leakage paths. âŁCommon failure modes illustrate these interactions – âa seized impeller orâ blocked inletâ reduces flow⢠despite motor⤠voltage, worn motor bearings⤠or âŁbrush wear produces⤠noise and reduced RPM, âŁand a split seal âor cracked housing causes leaks even if theâ motor runs.â Replacing the pump typicallyâ resolves symptoms such âas no drain, weak flow, humming without rotationor visible leakage, butâ verification with a multimeter, inspection ofâ the discharge hose andâ check â˘valveand confirmation ofâ control-board output will identify weather the fault is mechanical, electricalor hydraulic before replacement.
- No drain or slow drain: possible impeller clogâ or⢠hydraulic restriction.
- Humming but no⤠spin: electrical rotor stall,⢠seized bearingsor jammed debris.
- Leaking at pump housing or seals: mechanical seal failure or⢠crackedâ housing.
- Intermittentâ operation: wiring harness, connector corrosionor control output⣠issue.
| Item | Description |
|---|---|
| Mechanical | Impeller, housing, bearings and mounting interface that create flow and resist⤠leaks. |
| Electrical | Motor windings, âconnector pins â˘and control input that determine when and how⤠the pump is driven. |
| Hydraulic | Inlet/outlet hoses,check valve,and system backpressure⢠thatâ set actual flow rateâ and head. |
Common failure Symptoms and Diagnosticâ Tests for Pumpâ Motor, Impeller,â and Seals
The 137311900 Frigidaire⣠Washer Pump is a combined motor-and-impeller assembly that evacuates⢠wash âwater through the â˘drain system â¤while relying on a shaftâ seal to keep fluids awayâ from the motor windings. âIn normal operation the motor⢠produces sufficientâ torque to⤠spin the impeller against hydraulic and debris load; failures typically present as loss of flow, âunusual noise, humming without rotationorâ external leakageâ whereâ the seal or âhousing has been compromised. Because the âŁpump is an integrated mechanical and â˘electrical component,compatibility is dictated by mountingâ points,connector âŁtype,and seal â¤orientation rather than cosmetic â¤appearance-replacement units must match these interfaces â˘to ensure proper⢠fit andâ reliableâ shaft sealing under load. Practical examples include a⣠trapped sock that reduces flow and increases âŁmotor current, âŁor a failed seal âthat allows water intrusion âand âprogressive winding damage.
Technicians diagnose pump problems through a combination of visual, mechanical and electrical checks.First, visually inspect the housing âand âimpeller for foreign objects and evidence â¤of leaks; manually confirm the impeller rotates freely and without⤠axial play. For âelectrical verification, disconnect power before accessing wiring, then measure continuity across the motor terminals (shoudlâ show a closedâ winding) and insulation to chassis (should be open/no continuity). âDuring a controlled drain cycleâ measure voltage at the pump connector (nominally ~120 VAC on most U.S. machines) âŁand compare motor current to service data-a hum â¤with low/no rotation typically indicates mechanical binding or a âseized âimpeller, while normal rotation⢠with low flow points to â¤impeller âdamage⤠or partial blockage.If the pump passes â˘bench electrical tests but leaks or noise âŁpersist, replace the assembly to restore⤠reliable âsealing and hydraulic performance.
- No drain: â˘inspect for obstructions, confirm voltage at connector, verify continuity of motor windings.
- Humming without âspin: check impeller for jams,measure motor â˘current for overload,confirm shaft⤠turns⤠freely by hand.
- Intermittent operation:⣠inspect âwiring harness âand connectors, test switch/relay operation that suppliesâ the âpump.
- External leakage: examine shaft seal and housing for cracks or coolant tracks; replace pump ifâ seal integrity⤠is âlost.
- Excessive⢠noise âor vibration:â look for debris trapped against the impeller, worn bearingsor bentâ impeller blades.
| Item | Description |
|---|---|
| Continuity test | Closed winding between â¤motor terminals; no continuity between â¤windings and chassis (no short to ground). |
| Voltage âŁcheck | Measure supply at connectorâ during drain command (nominallyâ ~120â VAC on âU.S. models)⤠to⤠isolate control vs. â¤pump failure. |
| Impeller spin | Impeller âŁshould rotate âsmoothly by hand; binding indicates obstruction or bearing⢠failure⢠causing high current draw. |
| Leak inspection | Visual check for â˘coolant/water at the pump seam âor shaft; wetness at motor indicates seal failure and likely replacement. |
Replacement Considerations and Step-by-Step Installation âfor⤠the 137311900 Pump Assembly
The 137311900 Frigidaire Washer Pump âŁis a motor-driven drain âŁpump assembly that moves wash water from the tub to the household drain during drain and spinâ cycles. It â¤consists of a small electric motor, an impellerand a molded housing with inlet and â˘outlet ports; electrical activation⤠and run âtime are âcontrolled by the washer’s control board or timer. Technically, compatibility hinges on mechanical mounting, inlet/outlet orientationand â¤the electrical connector typeâ – â˘verify that the pump’s â˘mounting tabs, hose⣠diametersand terminal style matchâ the machine before replacement. Common failure modes include seized bearings, âclogged impellers, worn âbrushes â(in brushed motors)and housing leaks; troubleshooting often begins with verifying continuity âat theâ pump terminals⤠and checking for obstruction in the discharge âŁhose or coin trap.
Replacement requires basic hand tools and attention to wiring and sealing details. â¤before beginning, disconnect power and shut offâ the water supply, then drainâ residual â¤water from the tub to limit spillage. Remove âthe access panel,document⣠the hose and wiring configuration with a photo or labels,remove⤠hose âclamps and electrical connector,and unfasten â¤the⣠pump âŁmounting screws. When âinstalling⣠the new â˘pump, transfer or replace⣠any gaskets, position the unit so⣠inlet/outlet âŁorientation matches âŁthe âoriginal, secure the mounting hardware evenly, reconnect hoses with new orâ inspected clampsand restore power for a shortâ drain test whileâ checking for leaksâ and abnormal noise. Practical tips: replace brittle hoses or clamps, avoid overtightening clamps on⣠plastic fittingsand runâ aâ diagnostic drain/spin to confirm âboth electrical operation and hydraulic sealing.
- Power⤠off andâ water off; drain tub before disconnecting hoses.
- Labelâ or photograph âelectrical connectors âŁand hoses for correct reinstallation.
- Remove mounting⣠screws and clamps; extract â¤the âold pump and inspect gaskets.
- Install â˘new pump, â¤transfer⣠gasket, reconnect hoses and terminals, â¤then secure âclamps.
- Restore power âand run a short drain cycle; check for leaks and⤠listen for abnormal âvibration.
| Item | Description |
|---|---|
| Voltage | Typically 120 â˘VAC for â¤North American household washers; confirm with service manual. |
| Connector | Quick-disconnect terminals (2 or 3 pin depending onâ model);⤠verify harness⢠compatibilityâ before installation. |
| Mounting | Screw-tab or âŁbracket-mounted housing – check tab spacing and orientation against âthe machine chassis. |
| Common symptoms | Humming motor âŁwith no discharge, water remaining after⣠drain cycle, visible leaksorâ excessive⣠noise. |
Q&A
What is â¤the Frigidaire part 137311900?
The 137311900 is the OEMâ drain pump assembly used on certain Frigidaire â˘(and⤠some Kenmore/White-Westinghouse) top-load andâ front-load washing âmachines. It is âŁindeed responsible for pumping⣠the wash water out of the tub and into the⢠household âdrain during â¤drain and spin⣠cycles. Always âconfirm compatibility with â¤your washer model number beforeâ purchasing.
What are the common symptoms âof â¤a failingâ 137311900 â¤washer pump?
Typical signs include: washer won’t drain orâ spins with water still⢠in the tub, âa⢠loud âgrinding â¤or humming noise during drain,⢠intermittent⣠draining, visibleâ leaks from the pump â˘area,⤠orâ machine âerror codesâ related to drainage. Some âsymptoms canâ also be caused by clogged hoses or blocked pump impellers by debris or small items.
How can I test the 137311900 pump âto see if it’s defective?
First disconnect power to the washer.â Remove the pump electrical connector⤠and use a multimeter to check for continuity â˘across the pumpâ motor terminals – an open circuit indicates a failed motor.⢠You can also check for obvious mechanical blockage by inspecting the impeller and housings for⢠debris.⣠If the motor gets power during a drain âcycle â˘but â˘doesn’t run, theâ pump âŁis likely âbad.
Can the â137311900 pump be repaired or âshould it be replaced?
Minorâ issues like â¤debris-jammed impellers or torn hoses/clamps can often be fixed without replacing the pump. Though,⢠if the motor has burned âout, bearings are noisy/worn, â˘seals⢠are⢠leakingor electrical components⢠fail, replacement is the recommendedâ solution. âAs drain â˘pumps are ârelatively inexpensive and⤠critical⢠to operation, most technicians replace rather than rebuild them.
How do I replace the 137311900 pump safely?
Unplug the washer and⣠turn off âthe waterâ supply. Access âthe â˘pump byâ removing the âappropriate access panel (front/bottom or back depending on model). Note hose⢠and wiring locations, then disconnect the drain hoses (expect some residual â¤water), release hose clampsand unplug the electrical⣠connector. â¤Remove mounting screws or clips and remove the old â¤pump, then install the new unitâ in reverse order. Tightenâ clamps, âreconnect âwiring, restore powerand run a short drain â˘cycle to check for leaksâ and proper operation.If unsure, hire a qualified appliance⢠technician.
Doâ I need any special âtools or parts to install the 137311900?
Basicâ hand toolsâ (screwdrivers,⣠pliers, nut⣠drivers) and possibly a putty knife to releaseâ clips are usually sufficient.You’ll need replacement hose clamps⤠if the originals are damaged. It’s a good idea âto have a towel âor small tray to catch water.⣠No⣠special âelectrical tools are â˘required beyond âa multimeter âŁif you plan to â¤test continuity.
Whyâ doesâ the ânew⣠pump âstill not drain after⣠installation?
If a â˘new pump doesn’t drain,⣠check for kinks orâ clogs in the drain hose orâ household drain, â˘verify the pump⢠electrical connector is âŁfully seated, âand confirm the pump isâ getting âŁvoltage during the drain cycle (use a multimeter carefully).Also verify⤠the â¤washer’s control board or timer âis calling for the pump â- a control fault or failed pressure⤠switch can⤠prevent the âpump fromâ running even⣠if the⢠pump⣠is good.
Is there anything I⤠should know â˘about buying a replacement 137311900⣠pump?
Buyâ a pump that specifically lists compatibility withâ your washer model – OEM parts ensure fitâ and âperformance. Aftermarket pumps can be acceptable but verify â¤fit,â connector type, â˘and⤠mounting âpoints. Check the seller’s return â¤policy and warranty. Keep the old âŁpump until you â˘confirmâ the new⤠one works, soâ you can compare connectors and hoses if needed.
The Way Forward
the 137311900 âFrigidaire washer pump⤠plays a⣠central role in âthe washing cycle by managing water âremoval and supporting overall appliance performance. As âan engineered component âdesigned to work withâ specific Frigidaire models, it contributes toâ efficient drainage, reliable cycleâ completion,â and protection of internal components from water-related wear.Proper selection and installation of this pump âŁhelp maintain⣠the washer’s operational integrity â¤and prolong its service life.
As symptoms such as âŁpoor drainage,⤠unusual noisesor cycle interruptions⤠can stem from⢠several causes, âaccurate diagnosis⣠is essential before replacing the pump.â Confirming âŁa âpump failureâ -⢠ideally through manufacturer guidance⢠or a qualified technician’s assessment – ensures âthat replacement is necessary and that the correct â˘137311900 unit is used. Timely,⣠appropriate replacement when needed restores function, reduces the risk of secondary damageand âsupports continued, reliable washer performance.
